.The kit consists of 11 main components which include the tools recommended by the manufacturer to set No.1 cylinder at TDC. It is important that the correct process is followed when setting up these engines.
Item | Description | OEM |
A | Camshaft Control Valve Removal Tool | T10352 |
B | Camshaft Clamp (Exhaust) | T40271-1 |
C | Camshaft Clamp (Inlet) | T40271-2 |
D | Oil Pump Tensioner Locking Pin | T40265 |
E | Tensioner Locking Pin 1.4 mm | T40011 |
F | Timing Chain Tensioner | T40267 |
G | TDC Positioning Tool | T10170 |
H | Dial Test Indicator | VAS6079 |
I | Crank Counter Hold Tool | T10355 |
J | Crankshaft Thrust Piece | T10368 |
K | Drift for Camshaft Slide Pieces | T40196 |
<td width="151" valign="top" style="width:151px;border-top:none;b
Manufacturer | Model | Size | Engine Code | Year |
Audi | A4 quattro | 1.8 | CDHB | 2008 |
A4 quattro | 2.0 | CDNC | 2008 | |
A4 quattro | 2.0 | CFKA | 2009 | |
A5 Coupe/Cabriolet | 1.8 | CDHB | 2009 | |
A5 Coupe/Cabriolet | 2.0 | CDNB | 2008 | |
A5 Coupe/Cabriolet | 2.0 | CDNC | 2008 | |
A5 Sportback | 1.8 | CDHB | 2009 | |
A5 Sportback | 2.0 | CDNB | 2009 | |
A5 Sportback | 2.0 | CDNC | 2009 | |
A6 | 2.0 | CDNB | 2012 | |
Audi | Q3 | 2.0 | CCZC | 2011 |
Q3 | 2.0 | CPSA | 2011 | |
Q5 | 2.0 | CDNB | 2009 | |
Q5 | 2.0 | CDNC | 2008 | |
TT | 1.8 | CDAA | 2008 | |
TT | 2.0 | CCZA | 2008 | |
TT | 2.0 | CESA | 2010 | |
TT | 2.0 | CETA | 2010 | |
A4 | 1.8 | CJEB | 2012 | |
A4 quattro | 1.8 | CJEB | 2012 | |
A5 Coupe/Cabriolet | 1.8 | CJEB | 2011 | |
A5 Sportback | 1.8 | CJEB | 2011 | |
Seat | Alhambra | 2.0 | CCZA | 2010 |
Altea/Altea XL | 1.8 | CDAA | 2009 | |
Altea/Altea XL | 2.0 | CCZB | 2009 | |
Exeo | 1.8 | CDHA | 2010 | |
Exeo | 1.8 | CDHB | 2010 | |
Exeo | 2.0 | CDND | 2010 | |
Leon | 1.8 | CDAA | 2009 | |
Leon | 1.8 | CDAA | 2011 | |
Leon | 2.0 | CCZB | 2009 | |
Toledo | 1.8 | CDAA | 2009 | |
Toledo | 2.0 | CCZB | 2009 | |
Skoda | Octavia II | 1.8 | CDAA | 2008 |
Octavia II | 1.8 | CDAB | 2009 | |
Octavia II | 2.0 | CCZA | 2008 | |
Superb II | 1.8 | CDAA | 2008 | |
Superb II | 1.8 | CDAB | 2009 | |
Superb II | 2.0 | CCZA | 2009 | |
Yeti | 1.8 | CDAA | 2009 | |
Yeti | 1.8 | CDAB | 2009 | |
Volkswagen | Eos | 2.0 | CCZA |
|
